Distribute the online help for user alarms over several HTML files
You have the option of distributing the online help for user alarms over several HTML files.
1. Create an XML file with the name "sinumerik_alarm_plc_pmc.xml" in the following
directory: /oem/sinumerik/hmi/hlp/<lng>/ or /user/sinumerik/hmi/hlp/<lng>/
<lng> stands for the language code, e.g. deu, eng, etc. When you create a language
directory, use the language code from the table in Section Supported languages
(Page 656)
2. Open the XML file and in the tag <NUM_AREAS> enter the number ranges of the alarms
and the corresponding HTML files.
3. Store the HTML files, specified in the XML file, in the following directory:
/oem/sinumerik/hmi/hlp/<lng>/sinumerik_alarm_plc_pmc or
/user/sinumerik/hmi/hlp/<lng>/sinumerik_alarm_plc_pmc file
Example: Creating an XML file
Entry Meaning
<BOOK> Help book
<NUM_AREAS> Number ranges of the alarms and the reference to the particular HTML file
The following example includes the online helps for the
alarms from 500000 to 599999 in the HTML file "sinumerik_alarm_oem_1.html",
the alarms from 600000 to 699999 in the HTML file "sinumerik_alarm_oem_2.html",
the alarms from 700000 to 799999 in the HTML file "sinumerik_alarm_oem_3.html",
the alarms from 800000 to 899999 in the HTML file "sinumerik_alarm_oem_4.html".
<?xml version="1.0" encoding="utf-8" standalone="yes"?>
<!DOCTYPE HMI_SL_HELP>
<HMI_SL_HELP>
<BOOK>
<NUM_AREAS>
<NUM_AREA from="500000" to="599999" ref="sinumerik_alarm_oem_1.html" />
<NUM_AREA from="600000" to="699999" ref="sinumerik_alarm_oem_2.html" />
<NUM_AREA from="700000" to="799999" ref="sinumerik_alarm_oem_3.html" />
<NUM_AREA from="800000" to="899999" ref="sinumerik_alarm_oem_4.html" />
</NUM_AREAS>
</BOOK>
</HMI_SL_HELP>
Replacing the standard online help
You have the option of generating your own online help for the HMI, NC and PLC alarms as
well as machine data. This means that you can replace the standard online help by your own
online help.
You can call your own online help directly at the control using the INFO key. Instead of the
standard online help, your own online help is displayed.
OEM-specific online help
19.6 Generating online help for user alarms and machine data
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 493
