= 1 Tapping also possible without encoder
Bit 3 Constant cutting speed referred to the diameter of the centering
= 0 Constant cutting speed referred to the diameter of the tool
= 1 Constant cutting speed referred to the diameter of the centering
MD52229 $MCS_ENABLE_QUICK_M_CODES Enable fast M commands
= 0
Bit 0 Coolant OFF (default value)
Bit 1 Coolant 1 ON
Bit 2 Coolant 2 ON
Bit 3 Coolants 1 and 2 ON
MD52230 $MCS_M_CODE_ALL_COOLANTS_OFF M code for all coolants Off
= 9 You define the M function to switch off the coolant that is output when the tool is changed.
MD52231 $MCS_M_CODE_COOLANT_1_ON M code for coolant 1 On
= 8 You define the M function for coolant 1 that is output when the tool is changed.
MD52232 $MCS_M_CODE_COOLANT_2_ON M code for coolant 2 On
= 7 You define the M function for coolant 2 that is output when the tool is changed.
MD52233 $MCS_M_CODE_COOLANT_1_AND_2_ON M code for both coolants On
= -1 You define the M function for coolant 1 and 2 that is output when the tool is changed.
MD52281 $MCS_TOOL_MCODE_FUNC_ON[ ] M code for tool-specific function ON
= -1 M function is not output.
If both M commands of a function "= -1", the corresponding field is not displayed on the
interface.
[0] M code for tool-specific function 1 ON
[1] M code for tool-specific function 2 ON
[2] M code for tool-specific function 3 ON
[3] M code for tool-specific function 4 ON
MD52282 $MCS_TOOL_MCODE_FUNC_OFF[ ] M code for tool-specific function OFF
= -1 M function is output.
If both M commands of a function "= -1", the corresponding field is displayed on the interface.
[0] M code for tool-specific function 1 OFF
[1] M code for tool-specific function 2 OFF
[2] M code for tool-specific function 3 OFF
[3] M code for tool-specific function 4 OFF
Technologies and cycles
21.4 Milling
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 521
