$TC_CARR37[n] Display variants of the input screens for CYCLE800
Decimal place Meaning
THOUSANDS Selection field direction: Direction selection of the rotary axes
0 = No display of the direction reference for kinematics that only have
one solution. Direction selection (_DIR) Minus is generated in the
cycle call CYCLE800.
3 = Direction reference, rotary axis 1, direction selection Minus in the
basic setting of the kinematics.
4 = Direction reference, rotary axis 2, direction selection Minus in the
basic setting of the kinematics.
5 = No display of the direction reference for kinematics that only have
one solution. Direction selection (_DIR) Plus is generated in the
cycle call CYCLE800.
8 = Direction reference, rotary axis 1, direction selection Plus in the
basic setting of the kinematics.
9 = Direction reference, rotary axis 2, direction selection Plus in the
basic setting of the kinematics.
The values 1, 2, 6 and 7 are not permitted.
TEN THOUSANDS Selection field, correction of the tool tip or B axis kinematics
0 = No display of the correction of the tool tip input field.
1 = Correction of tool tip by means of TRAORI.
2 = No correction of tool tip + B axis kinematics turning technology.
3 = Correction of tool tip + B axis kinematics turning technology.
The Correction of tool tip function requires the "5-axis transforma‐
tion (TRAORI)" option.
HUNDRED THOU‐
SAND
Basic position of the kinematics
1)
0 = Corresponding to the working plane G17, G18 or G19 (compati‐
bility)
1 = Tool axis in the Z direction
3 = Tool axis in the X direction
ONE MILLION TEN
MILLION
Selection field, retraction
00 = No retraction
01 = Retraction Z
02 = Retraction Z, XY
03 = Retraction Z or Z, XY
04 = Maximum retraction in tool direction
...
08 = Incremental retraction in tool direction
...
15 = Retraction Z or Z, XY or
in maximum tool direction or in incremental tool direction
$TC_CARR38[n] Retraction position X
$TC_CARR39[n] Retraction position Y
$TC_CARR40[n] Retraction position Z
Technologies and cycles
21.7 Swiveling
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 575
