General sequence
The machine manufacturer must execute the following steps to make the required data
available:
1. Creating a PLC user program which activates the device during activation on the PLC.
2. Commissioning of the "standard machine" followed by backup of the data in a series startup
archive.
3. Installation of the devices, commissioning, followed by read-out of the data as a differential
series startup archive.
Note
Changing the machine configuration
Should there be any need to edit the drive machine data, this should be adapted in the
control first. This procedure should be repeated for all devices and constellations.
Adding axes
If the machine is extended with machine axes, it is important to install the drive objects (DO)
in a fixed sequence because the series startup archive contains the constellation of the
machine manufacturer's reference machine and cannot be applied if the sequence is changed.
It is recommended that the following settings be selected for the "control components":
● NC data
● PLC data
● Drive data
– ACX format (binary)
Generating commissioning dialogs
2.2 Configuration in the PLC user program
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 179
