Operation
7.2 Functions of the inputs and outputs
106 Manual, 08/2017, L1V30368969104A-02
Functions of the inputs and outputs
In this section, the functions of the inputs and outputs described in the section titled
Connecting the control circuit (Page 72) are explained in more detail.
Some points in this chapter are only relevant for the 3KC4 or 3KC8 transfer switching
equipment. Please pay particular attention to these important notices.
Inputs and outputs of the motor operator
The inputs of the motor operator are located in the following positions:
Figure 7-9 Inputs of the motor operator
