Siemens SENTRON - Connecting the Control Circuit

Connection
6.3 Connecting the control circuit
72 Manual, 08/2017, L1V30368969104A-02
6.3
Connecting the control circuit
In the following chapter, you will find a description about the connection of the motor
operator of the 3KC4 and 3KC8 transfer switching equipment.
Note
The procedure when connecting the motor operator differs in part between the 3KC4 and
3KC8 transfer switching equipment. Please pay particular attention to these important
notices.
6.3.1
Inputs and outputs of the motor operator
6.3.1.1
Overview of motor operator
The motor operator has the following Inputs and outputs:
Figure 6-50 Overview of inputs and outputs for 3KC4 and 3KC8 transfer switching equipment
Note
You can find more information on the function of the inputs and outputs in the section titled
Functions of the inputs and outputs (Page 106).
