Operation
7.2 Functions of the inputs and outputs
Manual, 08/2017, L1V30368969104A-02
121
Pin 415: Manual return transfer
This command prevents automatic return transfer of source II to source I. In other words,
even if source I is available again, the 3KC8 transfer switching equipment remains in switch
position II and must be switched back manually. The command becomes active when
contacts 415 and 417 are closed.
If the contact is opened, the transfer switching equipment changes to switch position I after
expiry of the set delay times (higher priority due to network/generator application) when
source I is available again.
Pin 416: Inhibition of automatic mode
This command inhibits the automatic mode of the electronic module without activating
another operating mode. In this way, the 3KC8 transfer switching equipment can be
operated only in manual operation (using the handle) or in remote mode (using inputs 313-
317 on the motor operator).
Pin 417: Common control terminal of inputs 413-416
Pin 417 is used as the common control terminal for inputs 413-416.
7.2.3.4
Functions of the control inputs for network / network application
Designation
Pin
Explanation
Properties
Recommended cable
cross-section
Control inputs of the
electronic module
207 Common control terminal for inputs
208-209
Use only with floating
contacts and supply
via pin 207
1.5 - 2.5 mm
2
208 Inactive
209 Selection of the prioritized source
(if 413 and 417 are open)
210 Inactive
413 Priority of a source Use only with floating
contacts and supply
via pin 417
1.5 - 2.5 mm
2
414 Inactive
415 Manual return transfer
416 Inhibition of automatic mode
417 Common control terminal for inputs
413-417
NOTICE
Damage to the device
Do not connect inputs 207 to 209 to the power supply.
Do not connect inputs 413 to 417 to the power supply.
