Siemens SENTRON - Electronic Module (3 KC8 Only)

Accessories
9.18 Electronic module (3KC8 only)
Manual, 08/2017, L1V30368969104A-02
175
9.18
Electronic module (3KC8 only)
The electronic module of the 3KC8 transfer switching equipment can be replaced with a new
electronic module in the event of a defect.
Figure 9-46 Electronic module 3KC9826-0
Current rating
Product number
250 A … 3200 A 3KC9826-0
Replacing the electronic module
1. To disassemble the electronic module, follow the corresponding steps 1 to 11 in the
section titled Motor operator (Page 170).
2. Dispose of the electronic module in an environmentally friendly way.
Figure 9-47 Disposing of the electronic module
3. To mount a new electronic module, follow steps 1 to 11 in the section titled Motor
operator (Page 170) in reverse order.
