Operation
7.2 Functions of the inputs and outputs
Manual, 08/2017, L1V30368969104A-02
115
7.2.3
Inputs and outputs of the electronic module (3KC8 only)
The 3KC8 transfer switching equipment contains inputs and outputs on the electronic
module in addition to the two inputs and outputs of the motor operator.
7.2.3.1
Inputs for voltage measurement and power supply
The inputs for voltage measurement and power supply on the electronic module are located
in the following positions on the electronic module:
①
Power supply input I
②
Voltage measurement supply source I
③
Voltage measurement supply source II
④
Power supply input II
Figure 7-11 Inputs and outputs of the electronic module
