9.11 Power supply kit 3KC9833-, 3KC9834- (2-pole, 3KC8 only)
Manual, 08/2017, L1V30368969104A-02
161
9.11
Power supply kit 3KC9833-, 3KC9834- (2-pole, 3KC8 only)
The power supply kit for a single-phase network with neutral consists of one phase and a
neutral conductor. This enables monitoring of the phase and the neutral conductor as well as
the power supply of the 3KC8 transfer switching equipment.
The power supply kit is described in the section titled Connecting power supply kit 3KC9833-
, 3KC9834- for single-phase network (Page 98).
Figure 9-23 Power supply kit 3KC9833-, 3KC9834-
The table below lists the possible variants depending on the arrangement of the load (on the
top or bottom) and the current rating.
Current rating
Number of poles
Position
Product number
250 A 3 poles Bottom 3KC9833-1
400 A 3 poles 3KC9833-2
630 A 3 poles 3KC9833-3
800 A … 1000 A 3 poles 3KC9833-4
1250 A 3 poles 3KC9833-5
1600 A 3 poles 3KC9833-6
2000 A … 3200 A 3 poles 3KC9833-7
250 A 3 poles Top 3KC9834-1
400 A 3 poles 3KC9834-2
630 A 3 poles 3KC9834-3
800 A … 1000 A 3 poles 3KC9834-4
1250 A 3 poles 3KC9834-5
1600 A 3 poles 3KC9834-6
2000 A … 3200 A 3 poles 3KC9834-7
