Accessories
9.17 Motor operator
170 Manual, 08/2017, L1V30368969104A-02
The motor operator of the 3KC4 and 3KC8 transfer switching equipment can be replaced
with a new motor operator in the event of a defect. It is possible to replace the motor
operator without disassembling the transfer switching equipment.
Figure 9-34 Motor operator
The required motor operator depends on the current rating. The table below lists the motor
operators according to current rating.
250 A … 400 A 3KC9826-1
630 A 3KC9826-2
800 A … 1250 A 3KC9826-3
1600 A 3KC9826-4
2000 A 3200 A 3KC9826-5
