Accessories
9.17 Motor operator
174 Manual, 08/2017, L1V30368969104A-02
9. Lift the electronic module to reach the connections.
Figure 9-44 Disconnecting the power supply
10.Disconnect the power supply of the transfer switching equipment (pin 301 and 302).
11.Release the clip assembly to remove the electronic module from the motor operator.
12.Dispose of the motor operator in an environmentally friendly way.
Figure 9-45 Disposing of the motor operator
13.To mount a new motor operator, follow steps 1 to 11 in the reverse order.
