Operation
7.2 Functions of the inputs and outputs
110 Manual, 08/2017, L1V30368969104A-02
Pin 316 - O: Command for transfer to position O
Closing of this contact has the result that the transfer switching equipment is switched to the
O position. This command is activated if the following requirements are met:
● The switch on the motor operator is in the "Auto" position
● Contacts 312, 316 and 317 are connected to one another
● Contact 313 is open
Pin 317 - COM: Common control terminal for inputs 312-316
Input 317 is used as the common control terminal for inputs 312-316.
Technical specifications for the control inputs of the motor operator
Number of inputs 5
Direct current I
in
0.35 - 0.5 mA
Line resistance 1 kΩ
Length of cable Maximum 100 m, cable cross-section min.: 1.5 mm
2
≙
16AWG
Minimum pulse duration 60 ms
Power per input 0.06 VA
Overvoltage protection 4.8 kV (1.2 μs / 50 μs)
ESD proof voltage (contact / air) 2 kV / 4 kV
Impulse voltage resistance U
imp
between inputs and other
current-carrying parts
4.8 kV (1.2 μs / 50 μs), increased insulation
Permissible cable cross-section min. 1.5 mm
2
/ max. 2.5 mm
2
