Technical specifications
11.3 Technical specifications of the electronic module
190 Manual, 08/2017, L1V30368969104A-02
Unit
3KC8 (250 to 3200 A)
Digital input
2)
Motor operator:
O position,
I position,
II position,
O position with priority,
release for remote control mode
Electronic module:
inhibition of automatic mode,
inhibition of automatic return transfer,
priority and selection of system,
test off load,
test on load,
priority for test on load,
deactivation of stabilization delay
Input delay ms 46
Number of relay outputs Motor unit: 4 NO
Electronic module: 1 NO 1 CO:
2A/250 V AC / 2A/24 V DC
Supplementary notes on relay
outputs
2)
Motor operator:
availability of the motor operator,
switch position I, O, II,
Electronic module:
availability of the device,
generator start/stop signal
Connections
Connecting terminals removable / plug-in
Connectable conductor cross-
section / stranded, solid
mm
2
1.5 ... 2.5
Connectable conductor cross-
section / solid
AWG 16 ... 14
Connectable conductor cross-
section / stranded
AWG 16 ... 14
Tightening torque Nm 0.5 ... 0.6
1)
In addition to the power loss of the motor operator
2)
You can find more information in the chapter on the functions of the inputs and outputs.
