Dimension drawings
12.2 Dimension drawings of the 3KC8 transfer switching equipment
Manual, 08/2017, L1V30368969104A-02
203
mm
2000 A
2500 A
3200 A
3P
4P
3P
4P
3P
4P
A 380 380 380 380 380 380
B 461 461 461 461 461 461
C 596 716 596 716 596 716
D 399 519 399 519 399 519
E 347 467 347 467 347 467
F 120 120 120 120 120 120
G 90 90 90 90 90 90
H 44 44 44 44 44 44
I 53 53 53 53 53 53
J 8 8 8 8 8 8
K1 67.5 67.5 67.5 67.5 67.5 67.5
K2 134 134 134 134 134 134
L 288 288 288 288 288 288
