Applications
13.2 Transfer between two sources with two outgoing loads
208 Manual, 08/2017, L1V30368969104A-02
Transfer with T1 (kVA) = T2 (kVA)
The transfer switching equipment also offers innovative approaches for connection to two
non-differentiated transformers with equal power (T1 (kVA) = T2 (kVA)).
Figure 13-3 Transfer T1 (kVA) = T2 (kVA)
Switching state of the
transfer switching
equipment
0 0 x OFF
1 0 P1 + P3 ON
0 1 P2 + P4 ON
1 1 P1 + P3 ON
