Connection
6.2 Connecting the main circuit
Manual, 08/2017, L1V30368969104A-02
45
800 A ... 1000 A M8 x 35 mm 13 8.3 ... 13
1250 A M10 x 40 mm 17 20 ... 26
1600 A M12 x 45 mm 19 40 ... 45
1. Position the bridging bar on the connecting terminal.
2. Fix the first half of the bridging bar to the connecting terminal.
– For current ratings of 800 A to 1250 A with 4 bolts, 8 washers, and 4 nuts.
– For current ratings of 1600 A with 2 bolts, 4 washers, and 2 nuts.
3. Fix the second half of the bridging bar to the connecting terminal.
– For current ratings of 800 A to 1250 A with 4 bolts, 8 washers, and 4 nuts.
– For current ratings of 1600 A with 2 bolts, 4 washers, and 2 nuts.
The two halves of the bridging bar must come into contact
before work step 4.
4. Connect the two parts of the bridging bar with the bolts supplied.
