Siemens Simantic ET200SP User Manual

Configuration control (option handling)
Distributed I/O system
174 System Manual, 12/2016, A5E03576849-AG
Procedure
To set up the configuration control, follow these steps:
Step
Procedure
See...
1
Enable configuration control in STEP 7
Section Configuring (Page 175)
2 Create control data record Section Creating the control data record
(Page 177)
3 Transfer control data record Section Transferring the control data
record in the startup program of the CPU
(Page 187)
Block library "OH_S71x00_Library"
The block library OH_S71x00_Library
(https://support.industry.siemens.com/cs/#document/29430270?lc=en-WW) is available for
download from the Internet. The block library contains data types with the structure of the
control data records for the ET 200SP distributed I/O system. You can implement your
flexible automation solution inexpensively with the help of these data types.
Note
Configuration control in the case of motor starters
"Manual local" mode is possible in the case of motor starters whe
n configuration control is
active. The motor starter works with the last valid parameters. Do not change the
parameterization while "manual local" mode is active.

Siemens Simantic ET200SP Specifications

General

System Type	Modular I/O System
Mounting	DIN Rail
Power Supply	24 V DC
Category	I/O Systems
Protection Class	IP20
Modularity	Yes
Communication Protocols	PROFINET, PROFIBUS
Digital Inputs	Available (varies by module)
Digital Outputs	Available (varies by module)
Analog Inputs	Available (varies by module)
Analog Outputs	Available (varies by module)
Number of Modules per Station	Up to 64
Module Width	15 mm, 20 mm, 22.5 mm (depending on module type)
