Siemens SIMATIC ET 200SP User Manual

User data variants
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
208 Manual, 07/2018, A5E42674880-AA
Reactive power L1L2L3 (ID 252 or FC
H
)
Table D- 4 Reactive power L1L2L3
Byte
Allocation
Data
type
Unit
Value range
Meas-
ured
value
ID
0
User data variant
BYTE
-
252 (FC
H
)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit string qq xx xx xx -
2 ... 3
Current L1
UINT
1 mA
0 … 65535
66007
4 ... 5
Current L2
UINT
1 mA
0 … 65535
66008
6 ... 7
Current L3
UINT
1 mA
0 … 65535
66009
8 ... 9
Reactive power Qtot L1
INT
1 var
-27648 … 27648
66022
10 ... 11
Reactive power Qtot L2
INT
1 var
-27648 … 27648
66023
12 ... 13
Reactive power Qtot L3
INT
1 var
-27648 … 27648
66024
14 ... 15
Total reactive power Qtot L1L2L3
INT
1 var
-27648 … 27648
66038
16 ... 19 Total reactive energy L1L2L3 DINT 1 varh -2147483647...
+2147483647
222
20
Power factor L1
USINT
0.01
0 … 100
66019
21
Power factor L2
USINT
0.01
0 … 100
66020
22
Power factor L3
USINT
0.01
0 … 100
66021
23
Total power factor L1L2L3
USINT
0.01
0 … 100
66037
24
Scaling current L1
USINT
-
0 ... 255
-
25
Scaling current L2
USINT
-
0 ... 255
-
26
Scaling current L3
USINT
-
0 ... 255
-
27
Scaling reactive power L1
USINT
-
0 ... 255
-
28
Scaling reactive power L2
USINT
-
0 ... 255
-
29
Scaling reactive power L3
USINT
-
0 ... 255
-
30
Scaling reactive power L1L2L3
USINT
-
0 ... 255
-
31
Scaling total reactive energy L1L2L3
USINT
-
0 ... 255
-

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
