Siemens SIMATIC ET 200SP User Manual

User data variants
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
212 Manual, 07/2018, A5E42674880-AA
Energy L1 (ID 248 or F8
H
)
Table D- 8 Energy L1
Byte
Allocation
Data
type
Unit
Value range
Meas-
ured
value
ID
0
User data variant
BYTE
-
248 (F8
H
)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit
string
qq xx xx xx -
2 ... 3
Current L1
UINT
1 mA
0 … 65535
66007
4 ... 7 Active energy inflow L1 UDINT 1 Wh 0 ... 2147483647 62110
8 ... 11
Active energy outflow L1
UDINT
1 Wh
0 ... 2147483647
62111
11 ... 15
Reactive energy inflow L1
UDINT
1 varh
0 ... 2147483647
62112
16 ... 19
Reactive energy outflow L1
UDINT
1 varh
0 ... 2147483647
62113
20 ... 23
Apparent energy L1
UDINT
1 VAh
0 ... 2147483647
62114
24
Scaling current L1
USINT
-
0 ... 255
-
25
Scaling active energy inflow L1
USINT
-
0 ... 255
-
26
Scaling active energy outflow L1
USINT
-
0 ... 255
-
27
Scaling reactive energy inflow L1
USINT
-
0 ... 255
-
28
Scaling reactive energy outflow L1
USINT
-
0 ... 255
-
29
Scaling apparent energy L1
USINT
-
0 ... 255
-
30
Reserved
BYTE
-
-
-
31
Power factor L1
USINT
0.01
0 … 100
66019

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
