Siemens SIMATIC IPC347G User Manual

Hardware description
A.3 Internal Connector
SIMATIC IPC347G
108 Operating Instructions, 10/2020, A5E50059993-AA
DisplayPort interface
5
GND
Ground
-
6
ML_Lane2+
DP data 2+
Input
7
ML_Lane1-
DP data 1-
Input
8
GND
Ground
-
9
ML_Lane1+
DP data 1+
Input
10
ML_Lane0-
DP data 0-
Input
11
GND
Ground
-
12
ML_Lane0+
DP data 0+
Input
13
CONFIG1
CONFIG1
-
14
CONFIG2
CONFIG2
-
15
AUX_CH+
Auxiliary channel+
Bidirectional
16
GND
Ground
-
17
AUX_CH-
Auxiliary channel-
Bidirectional
18
HPD
Hot Plug Detect
output
19
GND
Ground
-
20
DP_PWR
+3.3 V (fused)
power out
A.3 Internal Connector
A.3.1 Fan connector
The pin assignment in the table below applies to all fan connectors on motherboard.
