SIMATIC IPC347G
Operating Instructions, 10/2020, A5E50059993-AA
69
8.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
The device is in good working order.
The fan cover and filter pad are installed.
The device is closed.
The connected I/O devices meet the requirements for the respective area of application
(interference emission according to EN 61000-6-3 / IEC 61000-6-3, immunity to
interference according to EN 61000-6-2 / IEC 61000-6-2).
8.2 General technical specifications
See the note in "Applicability of technical specifications (Page 69)".
6AG4012-2...-.... (for details, refer to the ordering documentation)
481 × 176 × 509 (W × H × D in mm)
Detailed dimensional specifications can be found in "Dimension drawings (Page 78)".
13.3 up to 17 kg; depending on the equipment
• Input Rating:100 VAC to 240 VAC ; 6 to 3A; 60 to 50Hz
• Rated output power: 350W (+3.3V & +5V≤105W)
• Full load (100%, 350 W) at 82% efficiency
• Typical load (50%, 175 W) at 85% efficiency
Light load (20%, 70 W) at 82% efficiency
• +5 V/16 A, +3.3 V/19 A
105 W permitted in total
• +12 V1/17 A, +12 V2/17 A
• -12 V/0.3 A, +5 V
aux/2.5 A
The total sum of all voltages is max. 210 W
IP 20 on the rear according to IEC 60529
Protection class I compliant with IEC 61140
Device is designed for environments with pollution degree 2
