Technical specifications
8.3 Current/power requirements and power supply
SIMATIC IPC347G
70 Operating Instructions, 10/2020, A5E50059993-AA
Transient overvoltage
Device is designed for connection to supply with overvoltage category II (transient
overvoltages up to 2500 V)
Safety regulations
• IEC/EN/UL 61010-1
• IEC/EN/UL 61010-2-201
• IEC/EN/UL 62368
• CAN/CSA-C22.2 No. 61010-1
• CAN/CSA-C22.2 No. 61010-2-201
1
Only with protected installation, see "Notes on ambient and environmental conditions
(Page 24)"
8.3 Current/power requirements and power supply
8.3.1 Power requirements of the components (maximum values)
Component
Voltage
+5 V
+3.3 V
+12 V1
+12
V2(CPU)
-12 V
5 V aux
motherboard with processor and
heat sink
2.5 A
1.2 A
4.6 A
0.1 A
0.3 A
Front fan
0.5 A
Basic system
1
2.5 A
1.2 A
5.1 A
0.1 A
0.5 A
Expansions
Hard disk drive SATA
1
0.6 A
0.8 A
DVD ROM
1
0.9 A
0.8 A
DVD writer
1
1.1 A
1.4 A
Single lines of current (max. per-
mitted)
2
25 A
25 A
16 A
16 A
0.8 A
3 A
Total power consumption, permit-
ted
210 W
Efficiency of the power supply
1
AC power supply:
approx. 85% (230 V AC/120 V AC) with typical load (50%) and
82% (230 V AC/120 V AC) with full (100%) or light load (20%)
1
Depends on the selected device configuration.
2
The max. permitted accumulated power of the +5 V and + 3.3 V is 130 W.
