Expanding and assigning parameters to the device
6.3 Memory modules
SIMATIC IPC347G
48 Operating Instructions, 10/2020, A5E50059993-AA
5. Loosen the bracket by unscrewing its screw ① and place it ② on the expansion card.
6. Secure the bracket.
7. Close the device.
6.3 Memory modules
6.3.1 Usable memory modules
Dual channel memory
The motherboard provides two DDR4 memory sockets and supports dual channel technology.
The memory capacity of the device can be upgraded to a maximum of 32 GB. You can use
approximately 3.2 GB of this memory in a 32-bit operating system and much more in a 64-bit
operating system.
The table below shows the supported memory types of motherboard.
DDR4-2133Mhz-512M x 64-UDIMM-288 pin
DDR4-2133Mhz-1G x 64-UDIMM-288 pin
DDR4-2133Mhz-2G x 64-UDIMM-288 pin
