Expanding and assigning parameters to the device
6.2 Expansion cards
SIMATIC IPC347G
46 Operating Instructions, 10/2020, A5E50059993-AA
6.2 Expansion cards
6.2.1 Usable expansion cards
Expansion cards that comply with the following standards are supported:
• PCI; Rev 2.3
Expansion cards with 3.3 V and 5 V supply voltage can be operated
• PCIe; Gen. 1, Gen. 2, Gen. 3(only supported for PCIe X16 slot)
Note
Expansion card specification
The dimensions of the cards cannot exceed the specified dimensions. If the height of the card
exceeds the specified dimension, you may experi
ence contact problems, malfunctions and
difficulties with the assembly.
The permitted expansion card dimensions are
specified in the section Dimension drawing of
(Page 79).
The PCI card is limited to 5 V and universal board.
The total power consumption of the modules is not permitted to exceed 75W in total.
6.2.2 Installing expansion cards
Requirement
• You are familiar with the information on expansion cards and the conditions of use of
expansion cards, see "Useable expansion cards (Page 46)".
• The device is open, see important information in "Open the device (Page 44)".
