Device maintenance and repair
7.4 Installing operating system, software and drivers
SIMATIC IPC347G
Operating Instructions, 10/2020, A5E50059993-AA
65
3. Disconnect all cables from the motherboard.
4. Remove the nine screws indicated in the following figure.
7.4 Installing operating system, software and drivers
Information on installation of the operating system is available on the Internet:
• Microsoft® Windows® 10
(https://support.industry.siemens.com/cs/ww/en/view/109749498
)
Before installing Windows 10, set the "Boot mode select" as UEFI in BIOS. On how to set
the boot mode, refer to Boot menu (Page 94).
7.4.1 Installing software and drivers
Requirements
• Windows 10 operating system is installed in your IPC.
• You need to connect a mouse, a monitor and a keyboard to your PC.
• You also need the supplied USB stick to your PC.
