Technical specifications
8.8 Technical specifications of graphic
SIMATIC IPC347G
74 Operating Instructions, 10/2020, A5E50059993-AA
8.8 Technical specifications of graphic
See the note in "Applicability of technical specifications (Page 69)".
Graphic controller
Intel® HD Graphics, 3D engine (integrated in processor)
Graphics memory
Dynamic Video Memory Technology, uses 32 MB and 1.7 GB RAM in main memory
Resolutions/frequencies/colors
• DisplayPort up to 4096 × 2304 pixels at 60 Hz; color depth up to 32-bit/pixel
• VGA (VGA via DP to VGA adapter) up to 1920 × 1200 pixels at 60 Hz; color depth
up to 32 bits/pixel
8.9 Technical specifications of the interfaces
Observe the information in "Applicability of technical specifications (Page 69)" and use only
original connections of the I/O to be connected.
COM
On the rear panel:
• 2 × RS232/RS485/RS422 (9-pin header)
On the motherb
oard：
• 2 × RS232 (9-pin header)
DP Connection of a digital monitor
• 1 × DP
The maximum length of DP cable is less than 15 meters, and the
DP cable must comply with VESA DisplayPort standard.
VGA Connection of an analog monitor
• 1 × VGA
Keyboard Connection through PS/2 or USB port
Mouse Connection through PS/2 or USB port
USB On the rear panel:
• 4 × USB 3.0 (900 mA)
On the fron
t panel:
• 2 × USB 2.0 (500 mA)
On the motherboard:
• 2 × USB 2.0 vertical (500 mA)
• 2 × USB 2.0 (500 mA, 2-pin header)
Ethernet 2 × Ethernet interface (RJ45, 10/100/1000 Mbps)
Wake on LAN, remote boot supported.
Audio Realtek® ALC887, 5.1 channels, high definition audio codec.
• Micro
• Line In
• Line Out
