Expanding and assigning parameters to the device
6.4 Drives (HDD/SSD)
SIMATIC IPC347G
50 Operating Instructions, 10/2020, A5E50059993-AA
Follow the steps below to install memory module on motherboard memory sockets:
1. Press the retaining clips outward to unlock the memory socket.
2. Align a memory module on the socket. Note that the notch on the memory must match the
alignment key on the memory socket.
3. Insert and press the memory module into the socket until the retaining clips snap back to
the original place, and the memory module is seated properly.
6.4 Drives (HDD/SSD)
6.4.1 Installation options for drive
The drive modules are horizontal slot. The SSD and HDDs (with a 5.25” to 2.5” converter) can
be installed in the slots.
Note
If the device is permanently installed, mounted on telescopic rails, it can only be subjected to
the vibration stresse
s described below during operation.
The maximum permitted power loss of the expansion cards is 75 W.
