Siemens SIMATIC IPC347G

Technical specifications
8.6 Technical specifications of the drives
SIMATIC IPC347G
Operating Instructions, 10/2020, A5E50059993-AA
73
8.6 Technical specifications of the drives
See the note in "Applicability of technical specifications (Page 69)".
Information on the drives is available in your order documents.
Drive
Maximum number of drives
Types of drive
HDD
2 (depends on the selected
configuration)
• 3.5" SATA, 6 GB/s; 1 TB
SSD
1
• 256 GB
•
512 GB
8.7 Technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 69)".
Chipset
Intel® H110 Chipset PCH
Processor
• Intel® 6th and 7th generation Core or Pentium 14nm LGA 1151 socket Proces-
sor, support 65W CPU
Slots for memory modules
2 x DIMM slots for DDR4 2133, expandable to 32 GB
Main memory
4 up to 32 GB, DDR4 SDRAM PC4-3200T
Max. of 2.8 GB can be used for 32-bit versions of operating system and applica-
tions; see order documents for equipment
Power consumption per PCIe slot with
x4 expansion card, maximum permit-
ted
• 3.3 V / 3 A
• 12 V / 2.1 A
• 3.3 V
aux / 0.4 A
Power consumption per PCIe slot with
x16 expansion cards, max. permissi-
ble
• 3.3 V / 3 A
• 12 V / 2.1 A
•
3.3 V
aux
/ 0.4 A
Max.permitted power consumption
per PCI slot (5V,32-bit)
5V, 5A or 3.3 V, 7A; 12V 0.5A; 3.3 Vaux 0.4A
PCI modules with exclusive 5 V supply
≤ 25 W
Power loss per slot with max. ambient
air temperature 40 °C, permissible
≤ 25 W
Power loss of all slots with max. am-
bient air temperature 40 °C, permissi-
ble
≤ 75 W
In sum, the current for 3.3 Vaux may not exceed 1.2 A.
