Siemens SIMATIC S5 Equipment Manual

R 02/92
Contents
8
Technical Specifications
8.1
8.2
8.3
8.4
8.5
8.6
8.7
8.8
Technical Specifications of the Basic Module
1P 241 . . . . . . . . . . . . . . . . . . . . 8 – 1
Technical Specifications of the Encoder Matching Modules ., , . . . ... , ... , 8 – 1
Time Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 – 3
Basic Connector Assignment . . . . . . . . . . . . . . . . . . . . . . . . . ... , . . . . . . . . . . . 8 – 7
Spare Parts for
1P 241 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 – 8
Replacement Types for Resistor Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 – 9
Cables for Siemens Incremental Encoders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 – 10
Permissible Slots for the Digital Positon Decoder Module . . . . . . . . . . . . . . . . 8 – 11
1P 241 Equipment Manual
@ SiemenS AG 1989, Order No.: 6ES5 998-0KD21
8–1
