Siemens SIMATIC S5 Equipment Manual

Matching Module 3 for Absolute Encoders R 02/92
6.3.4 Layout of the Matching Elements
The layout shows the configurable elements.
6.3.5 Component Sets (Analog, 6ES5 271–IAEII)
.
Measuring range
Components
Quantity
Value
Designation
100
mV R29, R30 2 1 kQ IYo B54311
R31 1
100 kS2
IYo 654311
Iv R29 1 10 kQ 1% 654311
R30
9.1 kfd
1% B54311
R31
;
100 kQ
1% B54311
20 mA R29 1
25 !2
1% B54311
R30 1 18 G? 1’ZO B54311
R31 1 500 Q 1% B54311
The component set allows per channel conditioning of analog value encoders for the 1P 241. The
set contains the above items and a Cannon connector.
6–6
1P 241 Equipment Manual
@SiemensA(31989, order No.: 6E.S5998-0KD21
