Siemens SIMATIC S5 Equipment Manual

R 02/92
Programming Instructions
9.3.4 Parameter Assignment
SPDB : ~ = X, y
BEF : KS = KB
KS = AE
KS = SS
KS = SH
KS =
IW
KS = AW
KS = EW
KS = IS
KS = IV
KS = N1
KS = N2
KS = PR
KS = MB
KS = RV
x = Track number
The track number is dependent on the parameter
BEF:
BEF = AE, IW, AW, EW
0<
=
x <31 track number
BEF = SS, SH
x = 32 Zero shift Channel I
x = 33 Zero shift Channel 2
BEF = KB
x = any choice
Y
=
User data block number
1< y
<255
2< y <255 with S5–155U and S5–135U
Only output of identifier bits and control bits
Modifying the setpoints of a track
Software-based synchronizing
Hardware– based synchronizing
Output of the actual value
Output of the initial
setpoint
Output of the end setpoint
Inhibit interrupt
Inhibit interrupt for supplying the module with new
setpoints
Zero shift, read channel 1
Zero shift, read channel 2
Verify read
Calculate average value
Inhibit interrupt depending on direction
The identifier bits and the control bits are updated at each command.
ABIT : KY = x, y
x = Enable reset
x ><0 No reset
x = O Reset of the corresponding interrupt bit in the system
data
Y
=
lnterrlJPt bit number
o<y<7
Parameter ABIT only with S5–150U/S and S5–155U
1P 241 Equipment Manual
@ Siemens AG 1989, Order No.: 6ES5 998-0KD21
9 – 17
