Siemens SIMATIC S5 Equipment Manual

General Function Description
R 02/92
1.12.3 Depending on Direction
This function allows you to inhibit the interrupts for channel 1 and/or channel 2, depending on the
direction.
Channel
Inhibit Direction
Entry in Byte (Module Address
+n)
n=o
n=l
n=4
1 Backward
xl
F8
1 Forward
x2
F8
1
Backward and forward
x3
F8
2 Backward
lx
F8
2
Forward
2x
F8
2 Backward and forware
3x
F8
1.13 Read Zero Shift Value
This special function can be used to read the values of the zero shift.
Channel
Entry in Byte (Module Address +n)
n=()
n=l
n=4
1
E8
2
E9
The function is executed once with transfer of
E8/E9.
The zero shift values are indicated in the bytes of module address +4, +5 and +6.
1) This function is implemented as of firmware release R09. The standard function blocks sup-
port the special function starting with the release states given in the technical specifications
(--+ sections 9.2.6,9.3.6 and 9.4.6) for the library number.
1 – 24
1P 241 Equipment Manual
@ Siemens AG 1989, Order No: 6ES5 998-0KD21
