R 02/92
-
General Function Description
This special function allows you to use software to inhibit all interrupts of the module.
I
Entry in Byte (Module Address
+n)
1
The function is selected by transfer of
E3,
and deselected with another transfer of
E3.
The status of bits 5 and 6 in response message byte 7 (module address +7) indicates whether this
function is active.
Function active: bit 5 = 1
bit 6 = 1
The module does not trigger illegal interrupts during reparameterization and during changing cam
setpoints.
Entry in Byte (Module Address
+n)
n=O
n
=
1
n
=
4
E4
The function is selected by transfer of
E4,
and deselected by another transfer of
E4.
The status of bit 6 in response message byte 7 (module address +7) indicates whether this special
function is active.
Function active: bit 6 = 1
1) This function is implemented as of firmware release R09. The standard function blocks sup-
port the special function starting with the release states given in the technical specifications
(~
sections 9.2.6,9.3.6 and 9.4,6) for the library number.
1P
241 Equipment Manual
@ si(?M6M7S AG 1969, Order
No:’6ES5
998-0KD21
1 – 23
