Programming Instructions
9.2.5 User Data Block Assignment
The data block specified under parameter BGDB is assigned as follows:
From DW
Assignment
o
Work area of the function block
10
Channel 1 Track O
Channel 1 Track 1
;: Channel 1 Track 2
25 Channel 1 Track 3
30 Channel 1 Track 4
35 Channel 1 Track 5
40
Channel 1 Track 6
45
Channel 1 Track 7
50
Channel 1 Track 8
55 Channel 1 Track 9
60
Channel 1 Track 10
65
Channel 1 Track 11
Channel 1 Track 12
;!?) Channel 1 Track 13
80
Channel 1 Track 14
85
Channel 1 Track 15
90 Channel 2 Track 16
Channel 2 Track 17
1%
Channel 2 Track 18
105 Channel 2 Track 19
110 Channel 2 Track 20
115 Channel 2 Track 21
120
Channel 2 Track 22
125 Channel 2 Track 23
130
Channel 2 Track 24
135 Channel 2 Track 25
140
Channel 2 Track 26
145 Channel 2 Track 27
150 Channel 2 Track 28
155 Channel 2 Track 29
160
Channel 2 Track 30
165
Channel 2 Track 31
170
Zero shift
175 Clock pulse group (for SS1 module)
177
Hysteresis (for analog submodule)
179
Rotary axis function
180
Sofware-based parallel switching of K1 and K2
181 Verify-read
183 Calculate average value (for analog submodule)
185
inhibit interrupt depending on direction
187
= Free for user =
1P 241 Equipment Manual
@ sk31?WIW AG 1989, Order No.: 6ES5 998-0KD21
9–5
