Siemens SIMOCODE pro - Page 138

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
138 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Table 4- 48 DiagWrn2 – Warning diagnostics for SIMOCODE pro devices
Bit
Meaning
0
AM1 open circuit
1 DM-F safety-oriented tripping
2
DM-F monitoring interval for mandatory testing - test required
3 DM-F feedback circuit
4
DM-FL simultaneity
11
EM open circuit
12
EM short circuit
Table 4- 49 DiagWrn2 – Warning diagnostics for PROFINET pro devices
Bit
Meaning
5
TM2 level T >
6
TM2 sensor fault
7
TM2 out of range
8
AM2 level 0/4-20mA >
9
AM2 level 0/4-20mA <
10
AM2 open circuit
