Siemens SIMOCODE pro User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
139
DiagTrp1, DiagTrp2 – Trip diagnostics
Table 4- 50 DiagTrp1 – Trip diagnostics for SIMOCODE pro devices
Bit
Meaning
0
Hardware fault basic unit
1 Module fault
2
Temporary components
3
Configuration fault
4
Parameterization
5
Bus
6
PLC/DCS
7
Execution on-command
8
Execution stop-command
9
Feedback On
10
Feedback Off
11
Stalled positioner
12
Double 0
13
Double 1
14
End position
15
Antivalence
16
Test position feedback (TPF)
17
Power failure (UVO)
18
Operational protection Off (OPO)
19
Unbalance
20
Overload
21
Overload and loss of phase
22 Internal earth fault
23
External earth fault
24 Thermistor trip level
25
Thermistor short circuit
26
Thermistor open circuit
27
TM1 level T >
28
TM1 sensor fault
29
TM1 out of range
30
Level I >
31
Level I <
