1.3 Engineering a drive
1-38
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
Table 1-6 Engineering table for drive modules with digital interface
SIMODRIVE 6SN11 Assessment factors
power modules, type
Control unit, digital
DC link
capaciĆ
tance
1-axis version
High-Performance control
2-axis version
High-Performance control
2-axis version
High-Standard control
tance
6SN1118Ă- 6SN1118Ă- 6SN1118Ă-
-Ă0DJ21 -Ă0DJ23 -Ă0DK21 -Ă0DK23 -Ă0DM31 -Ă0DM33 mF
1–axis version
6SN11 2 . - 1AA00 - 0HA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
75
6SN11 2 . - 1AA00 - 0AA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
75
6SN11 2 . - 1AA00 - 0BA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
110
6SN11 2 . - 1AA00 - 0CA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
330
6SN11 2 . - 1AA00 - 0DA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
495
6SN11 2 . - 1AA00 - 0LA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
990
6SN11 2 . - 1AA00 - 0EA1 EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
990
6SN11 2 . - 1AA01 - 0FA1 EP 1.75
AP 1.85
EP 1.75
AP 2.2
EP 1.75
AP 1.85
EP 1.75
AP 2.2
2145
6SN11 2 . - 1AA00 - 0JA1
1)
EP 1.5
AP 2.1
EP 1.5
AP 2.45
EP 1.5
AP 1.85
EP 1
AP 2.2
2145
6SN11 2 . - 1AA00 - 0KA1
1)
EP 1.5
AP 2.1
EP 1.5
AP 2.45
EP 1.5
AP 1.85
EP 1
AP 2.2
4290
6SN11 23 - ā1AA02 - 0FA1
1)
EP 1
AP 1.85
EP 1
AP 2.2
EP 1
AP 1.85
EP 1
AP 2.2
2145
2–axis version
6SN11 2 . - 1AB00 - 0HA1 EP 1
AP 2.8
EP 1
AP 3.4
EP 1
AP 2.8
EP 1
AP 3.4
150
6SN11 2 . - 1AB00 - 0AA1 EP 1
AP 2.8
EP 1
AP 3.4
EP 1
AP 2.8
EP 1
AP 3.4
150
6SN11 2 . - 1AB00 - 0BA1 EP 1
AP 2.8
EP 1
AP 3.4
EP 1
AP 2.8
EP 1
AP 3.4
220
6SN11 2 . - 1AB00 - 0CA1 EP 1
AP 2.8
EP 1
AP 3.4
EP 1
AP 2.8
EP 1
AP 3.4
660
Assessment factors of individual modules for the electronics points (EP) and
gating points (AP) as well as permissible combinations of power modules
and control units (digital).
Only combinations with entered EP and AP values are permissible.
The data referring to the assessment factors EP and AP refer to the encoder
cable lengths that have been released for use.
Enter the values into Table 1Ć7.
Absolute encoder with EnDat interface
S An additional 0.4 EP for each absolute encoder in the elecĆ
tronics area
S SSI encoders require an external power supply - therefore no
additional electronic/gating points
1) With mounted fan or hose cooling.
