4.8 Permanent–magnet synchronous motor with field–weakening (PE spindle)
4-156
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
– ”Motor selection” dialog box for unlisted motor:
”Motor” field ”Motor type” field
–> Enter data –> Synchronous motor (SRM)
After ”continue”, the motor data and the pre–setting for the cur-
rent controller adaptation must be entered:
P No. Name Value Units
1103 Rated motor current A(rms)
1104 Maximum motor current (as for P1122) A(rms)
1112 Motor pole pair number –
1113 Torque constant Nm/A
1114 Voltage constant V(rms)
1115 Armature resistance Ohm
1116 Armature inductance mH
1117 Motor moment of inertia kgm
2
1118 Motor standstill current A(rms)
1122 Motor limiting current (as for P1104) A(rms)
1128 Optimum load angle (from SW 3.3) Degrees
1146 Maximum motor speed RPM
1149 Reluctance torque constant
(from SW 3.3)
mH
1180 Lower current limit adaptation 0 %
1181 Upper current limit adaptation 30 %
1182 Current controller data factor 30 %
1400 Rated motor speed RPM
– ”Measuring system/encoder” dialog box
Field
”Which motor measuring system are you using?” –> Enter data
The encoder data should be entered after ”continue”:
Incremental – without zero mark yes
Rotor position identification yes
Note: This results in, P1011 = 3XXX
Hex
Speed actual value inversion first remains like this
P1005 (encoder pulse number) _ _ _ _ _ _
– ”Operating mode” dialog box
– ”Complete the drive configuration” dialog box
After the data that has been set has been carefully checked, the
drive configuration is completed by pressing
”Accept this drive configuration”.
