4.8 Permanent–magnet synchronous motor with field–weakening (PE spindle)
4-157
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
3. Set PE specific parameters and activate the PE spindle (only for
unlisted motors)
– Enter or change the following parameters via the expert list.
P No. Name Value Units
1136 Motor short–circuit current A(rms)
1142 Speed at the start of field weaken-
ing
RPM
1015 Activate PE–MSD 1: Activated
0: De–acti-
vated
–
– Execute the ”calculate controller data” function
After this, the controller data is pre–assigned, PE–specific.
– Save the parameters in the FEPROM
– Carry–out a POWER–ON RESET
Note
This completes the basic commissioning.
The motor can be operated with these settings.
After this first commissioning, for reasons of accuracy, the rotor
position identification run must be executed with zero mark and the
angular commutation offset determined.
Reader’s note
Additional commissioning instructions/information regarding motor
optimization are provided in the following.
