1
1.1 What can ”SIMODRIVE 611 universal” do?
1-26
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
The following encoders can be connected when using ”SIMODRIVE
611 universal”:
– Resolver with pole pair numbers 1, 2, 3, 4, 5 and 6
– Incremental encoder with sin/cos 1Vpp up to 65535 pulses,
e.g. ERN 1387 from Heidenhain
– Absolute encoder with
sin/cos 1Vpp and interface with EnDat protocol,
e.g. EQN 1325 from Heidenhain (EnDat protocol)
– from SW 8.1
incremental encoders with TTL signals with control board, Order
No. 6SN1118–NH01–0AA, only for induction motors
Note
For a 2–axis control board, it is not possible to mix encoders with
sin/cos 1Vpp and resolvers.
Unlisted encoders can also be connected.
The encoders which can be connected are listed in Chapter A.4.
The following is valid for resolvers:
The selected resolver must match the motor.
For resolvers, pole pair number = 1 (P1018) or the pole pair
number of the motor (P1112) is permissible.
The equipment is integrated and adapted to the machine/system by
appropriately parameterizing it. The following possibilities are available
for start–up and for service:
”SimoCom U” parameterizing and start–up tool
(SimoCom U under Windows, refer to Chapter 3.3)
Display and operator unit
(on the control board front panel)
The control board has an interchangeable memory module with a non–
volatile data memory (FEPROM) to save the following data:
Firmware (system software)
User data
The ”SIMODRIVE 611 universal” control board can be flexibly used in
many applications as a result of its design.
Typical applications for this control board are, e.g.:
Textile machines
Packaging machines
Machine tools
Handling equipment
Conveyor and transport equipment
Machines to machine/handle wood, glass or ceramics, etc.
Which encoders
can be
connected?
Parameterizing
Data save
Where can
”SIMODRIVE 611
universal”
be used?
06.04
