5
5.9 Parameter overview of PROFIBUS–DP
5-308
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 5-38 Parameters for PROFIBUS–DP, continued
Parameters
No. Effec-
tive
UnitsMax.Stan-
dard
Min.Description
0918 PROFIBUS node address 0 0 126 – PO
... specifies the address of the drives as DP slave on PROFIBUS.
Note:
There is one node address for the control board, although it is designed for two drives.
When changing the parameter in one drive, the parameter in the other drive is automati-
cally adapted.
Every node connected to PROFIBUS must have a unique address.
0922 Telegram selection PROFIBUS
(from SW 3.1)
0 101 104 – PO
... is used to set the free configurability or to select a standard telegram.
––> Refer to Chapter 5.6.5
0945:65 Fault code – – – – RO
... the fault code, i.e. the number of the fault which occurred, is entered.
The faults which occurred, are entered as follows into the fault buffer:
– first fault which occurred ––> parameter with index 1
to
– Eight faults which occurred ––> parameter with index 8
Note:
The following belongs to a fault:
Fault code (P0945:65), fault number (P0947:65), fault time (P0948:65) and fault value
(P0949:65)
A description of the faults, the way in which they can be acknowledged as well as a list of
all the faults, is provided in Chapter 7.
This parameter is reset at POWER ON.
0947:65 Fault number – – – – RO
Note:
This parameter is of no significance.
0948:65 Fault time – – – ms RO
This parameter specifies at which relative system time, the fault occurred.
Note:
This parameter is set to zero at POWER ON, and the time is then started.
0949:65 Fault value – – – – RO
The supplementary information associated with a fault which occurred, is entered in this pa-
rameter.
Note:
A description of the faults, the way in which they can be acknowledged as well as a list of
all the faults, is provided in Chapter 7.
This parameter is reset at POWER ON.
5 Communications via PROFIBUS DP
04.9904.9904.9904.99
