5
5.9 Parameter overview of PROFIBUS–DP
5-309
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 5-38 Parameters for PROFIBUS–DP, continued
Parameters
No. Effec-
tive
UnitsMax.Stan-
dard
Min.Description
0952 Number of faults – – – – RO
The parameter specifies the faults which occurred after POWER ON an.
Note:
This parameter is reset at POWER ON.
0953 Warnings 800 – 815 – – – hex RO
0954 Warnings 816 – 831 – – – hex RO
0955 Warnings 832 – 847 – – – hex RO
0956 Warnings 848 – 863 – – – hex RO
0957 Warnings 864 – 879 – – – hex RO
0958 Warnings 880 – 895 – – – hex RO
0959 Warnings 896 – 911 – – – hex RO
0960 Warnings 912 –927 – – – hex RO
... indicates which warning(s) is (are) present.
Bit x = 1 warning yyy present
Bit x = 0 a warning is not present
Example:
P0955 = 0110 ––> bits 8 and 4 are set ––> warnings 840 and 836 are present
Parameter 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Bit
P0953 815|814|813|812|811|810|809|808|807|806|805|804|803|802|801|800
P0954 831|830|829|828|827|826|825|824|823|822|821|820|819|818|817|816
P0955 847|846|845|844|843|842|841|840|839|838|837|836|835|834|833|832
P0956 863|862|861|860|859|858|857|856|855|854|853|852|851|850|849|848
P0957 879|878|877|876|875|874|873|872|871|870|869|868|867|866|865|864
P0958 895|894|893|892|891|890|889|888|887|886|885|884|883|882|881|880
P0959 911|910|909|908|907|906|905|904|903|902|901|900|899|898|897|896
P0960 927|926|925|924|923|922|921|920|919|918|917|916|915|914|913|912
0963
(from
SW 4.1)
Baud rate PROFIBUS – – – – RO
... contains the actual baud rate of the PROFIBUS.
0 9.6 kbit/s
1 19.2 kbit/s
2 93.75 kbit/s
3 187.5 kbit/s
4 500 kbit/s
6 1500 kbit/s
7 3000 kbit/s
8 6000 bit/s
9 12000 kbit/s
10 31.25 kbit/s
11 45.45 kbit/s
5 Communications via PROFIBUS DP
