6.2 Positioning mode (P0700 = 3, from SW 2.1)
6-356
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
The following secondary conditions must be observed, dependent on
the axis type:
Table 6-10 Restrictions for axis/encoder
Axis/encoder
Restrictions
Rotary incremen-
tal encoder
The axis must be referenced after power–up.
Linear
absolute value
encoder
(e.g. LC 181)
none
Linear
axis
Rotary absolute
value encoder
(e.g.
EQN 1325,
P1021 = 4096)
Overflow after the number of revolutions entered in P1021 (multiturn reso-
lution, motor absolute value encoder).
For linear axis with encoder connected to the motor, the following is valid:
––> The maximum traversing travel is: P1021  effective spindle pitch
Example: EQN 1325, 10 mm spindle pitch
––> max. traversing distance = –20.48 m to 20.48 m
 The machine zero can be completely freely selected in the
range from –20.48 m to +20.48 m.
Rotary
axis
Incremental
encoder
The axis must be referenced after power–up.
axis
en-
dlessly
rotating
Absolute value
encoders
Motor encoder ––> max. revolutions in P1021 (e.g. 4096)
Note:
The same restrictions apply as for linear axes and rotary absolute value
encoders.
Secondary
conditions for
axis/encoder
