1.4 ”SIMODRIVE 611 universal E” control board
1-50
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 1-6 Overview of the drive–specific terminals, continued
Terminals Technical dataType
1)
Function
Drive A
Technical dataType
1)
Function
Drive B
No.
Technical dataType
1)
Function
Desig-
nation
No.Desig-
nation
O0.A X453.9 O0.B X454.9 Digital output 0
2)
DO Rated current per output: 500 mA
Max. current per output: 600 mA
Voltage drop, typical:
250 mV at 500 mA
Short–circuit proof
O1.A X453.10 O1.B X454.10 Digital output 1
2)
DO
Short–circuit proof
Note:
Parameterization of the output termi-
nals as well as the standard assign-
ment is described in Chapter 6.4.5.
Note:
 The power switched via these outputs is supplied via terminals P24/M24 (X431). This must be
taken into account when dimensioning the external supply.
 The digital outputs only ”function” if an external power supply is available (+24 V, T. P24/M24).
1) DO: Digital output
2) Can be freely parameterized
The digital outputs are updated in the interpolation clock cycle (P1010). This is supplemented by a
hardware–related delay time of approx. 200 µs.
