6.6 Analog inputs

6-539

SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition

Table 6-54 Parameter for the M

red

mode, continued

Parameters

No. Effec-

tive

UnitsMax.Stan-

dard

Min.Description

1244 Characteristic type, torque/power reduction

(SRM, ARM)

Characteristic type, force/power reduction

(SLM)

1 1 2 –

Imme-

diately

... defines whether the reduction is realized with a negative or a positive characteristic.

= 1 Negative characteristic

= 2 Positive characteristic

1259

(from

SW 3.7)

Torque/power reduction mot./gen. (SRM,

ARM)

Force/power reduction mot./gen. (SLM)

0 0 1 –

Imme-

diately

... defines how the torque/power reduction or force/power reduction is effective depending on

the state motoring/regenerating.

=0 Reduction is effective, motoring and generating

= 1 Reduction is only effective motoring

In an emergency situation, the axis can still be quickly braked for P1259 = 1.

6 Description of the Functions

01.99

! not 611ue !
