6
6.7 Analog outputs
6-554
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
0 (LSB
)
23 (MSB)Bit 781516
with shift factor = 0
with shift factor = 1
with shift factor = 8
with shift factor = 16
MSB = Most Significant Bit
LSB = Least Significant Bit
Analog output value
Fig. 6-60 Shift factor for analog output of 24–bit signals
0 (LSB
)
47 (MSB)Bit 783940
with shift factor = 0
with shift factor = 1
with shift factor = 8
with shift factor = 40
Analog output value
MSB = Most Significant Bit
LSB = Least Significant Bit
Fig. 6-61 Shift factor for analog output of 48–bit signals
Shift factor = 0
Shift factor = 2
200000H
–10.0
0
+10.0
Output
voltage [V]
000000H 400000H 600000H 800000H A00000H C00000H E00000H FFFFFFH
1st overflow 2nd overflow 3rd overflow 4th overflow
Offset = 0 V
Fine normalization= 100 %
Hexadecimal value
Fig. 6-62 Analog output voltage with overcontrol protection (P0631/P0638 = 1)
Shift factor
Voltage range
6 Description of the Functions
01.99
