Siemens SIMODRIVE 611 universal - Page 555

6
6.7 Analog outputs
6-555
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Shift factor = 0
Shift factor = 2
200000H
–10.0
0
+10.0
Output
voltage
[V]
000000H 400000H 600000H 800000H A00000H C00000H E00000H FFFFFFH
1st overflow 2nd overflow 3rd overflow 4th overflow
Offset = 0 V
Fine normalization= 100 %
Hexadecimal value
Fig. 6-63 Analog output voltage without overcontrol protection (P0631/P0638 = 0)
6 Description of the Functions
01.99
