A
A.3 List of motors
A-871
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
A.3.3 List of permanent–magnet synchronous motors without field
weakening, build–in torque motors (1FW6, from SW 6.1)
Table A-6 Motor code for 1FW6 motors (build–in torque motors)
Order No.
(MLFB)
Motor
code
n
max
n
rated
M
0
(100 K)
I
rated
(100 K)
P1102 [RPM] [RPM] [Nm] [A(rms)]
1FW6190–xxB07–2Axx 1862 59 59 732.0 17.8
Unlisted motors 1999 – – – –
Note:
x: Space retainer for the Order No.
Table A-7 Unlisted motor: Parameters for permanent–magnet synchronous
motors without field weakening
Parameters
No. Name Units Value
1102 Motor code number – 1999
1103 Rated motor current A(rms)
1104 Maximum motor current A(rms)
1112 Motor pole pair number –
1113 Torque constant Nm/A
1114 Voltage constant V(rms)
1115 Armature resistance (phase value)
(rotating field inductance: L
rotating field
= 1.5 
L
phase
)
Ω
1116 Armature inductance mH
1117 Motor moment of inertia kgm
2
1118 Motor standstill current A(rms)
1122 Motor limiting current A(rms)
1128 Optimum load angle Degr.
1136 Motor short–circuit current A(rms)
Motor code for
permanent–
magnet
synchronous
motors without
field weakening
(1FW6)
Parameters for
unlisted motors
(1FW6l)
A Lists
01.99
02.0308.02
