Siemens SIMOTICS T-1FW6 Configuration Manual

Technical data and characteristics
6.2 Data sheets and diagrams
1FW6 Built-in torque motors
Configuration Manual, 07/2017, 6SN1197-0AE00-0BP9
359
Technical data
1FW6190
Symbol
Unit
-xxB10-1Jxx
-xxB10-2Jxx
-xxB10-5Gxx
Data for main motor cooler *)
Maximum dissipated thermal power
Q
H,MAX
kW
4.47
4.47
4.47
Recommended minimum volume flow
H,MIN
l/min
6.67
6.67
6.67
Cooling medium temperature increase
ΔT
H
K
9.64
9.64
9.64
Pressure drop
Δp
H
bar
0.795
0.795
0.795
Data for precision motor cooler *)
Maximum dissipated thermal power
Q
P,MAX
kW
0.482
0.482
0.482
Recommended minimum volume flow
P,MIN
l/min
2.33
2.33
2.33
Cooling medium temperature increase
ΔT
P
K
2.98
2.98
2.98
Pressure drop
Δp
P
bar
0.795
0.795
0.795
*) Parallel connection of main and precision motor cooler
